Model

ELP-SUSB1080P01-BL170

Sensor

IMX291

Lens Size

1/2.8 inch

Pixel Size

2.9µm X 2.9µm

Max. Resolution

1920(H)X1080(V)

Compression format

MJPEG  / YUV2（YUYV）

Resolution & frame

1920X1080 MJPEG@ 50fps/ USB3.0 1920X1080 YUY2@ 50fps

1280X720 MJPEG@ 50fps / USB3.0 1280X720 YUY2@ 50fps

640X480MJPEG@ 50fps / USB3.0 640X480 YUY2@ 50fps

S/N Ratio

40dB

Dynamic Range

65dB

Sensitivity

1900mV/lux-sec@550nm

Mini illumination

0. 01lux

Shutter Type

Electronic rolling shutter / Frame exposure

Connecting Port type

USB3.0 High Speed

Free Drive Protocol

USB Video Class（UVC）

AEC

Support

AEB

Support

AGC

Support

Adjustable parameters

Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,
Gain, White balance, Backlight Contrast, Exposure

Lens Parameter

Wide angle fisheye L170 lens

(2.1/2.8/3.6/6/8/12mm/no distortion/fisheye lens optional)

Power supply

USB BUS POWER

Operating Voltage

DC5V

Working current

170mA~210mA

Working temperature

0～70℃

Board size /Weight

38*38mm

Cable

Standard 2M（1m optional)

Operating system request

WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc. ​

Linux with UVC (above linux-2.6.26) ​

MAC-OS X 10.4.8 or later

Android 4.0 or above with UVC
