Model

ELP-USB4KCAM30H-SH110

Sensor

1/2.8” SONY IMX415

Max Resolution

3840(H)*2160(V)

Sensitivity

0.65V/lux-sec@550nm

Pixel Size

1.45µm x 1.45µm

Video Compression

MJPEG / YUY2(YUYV) / H.264

Resolution & Frame Rate

3840x2160 MJPEG 60fps/ H.264 60fps / YUY2 15fps

2560x1440 MJPEG 60fps/ H.264 60fps /

1920x1080 MJPEG 60fps/ H.264 60fps / YUY2 60fps

1280x720 MJPEG 60fps/ H.264 60fps / YUY2 60fps

640x480 MJPEG 60fps/ H.264 60fps / YUY2 60fps

Image Processing Time

About 10 seconds after opening the preview software

Central Definition

1000LW/PH(Center)

S/N Ratio

30dB

Min illumination

0.2 Lux

Shutter Type

Electronic Rolling Shutter/ Frame Exposure

Connecting Port Type

USB 3.0 Interface &HDMI v1.4 Interface

AEC/AWB/AGC

Support

Adjustable Parameters

Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Compensation, Exposure

Lens Parameter

Display Modes & Power Supply

I.  USB Output (USB Bus Power)

II.  HDMI Output (Power by Portable Power Bank / Charging Adapter )

III.  USB Output +HDMI Output Simultaneous (USB Bus Power)

Operating Voltage

DC 5V

Working Current

700-780mA

Storage Temperature

-20°C to 80°C

Working Temperature

- 10°C to 70°C

USB Cable

1.5m cable with Type-C & USB 3.0 port (2m, 3m optional)

HDMI Cable

1.5m cable with HDMI ports

Operating System Request

Win7/Win8/Win9/Win10/Win11 etc.

Linux with UVC

MAC-OSX10.4.8 or later

Android5.x or above
