16MP high resolution 2.8-12mm UVC mini micro webcam usb driver free for windows linux Mac OS

Model: ELP-USB16MP01-SFV(2.8-12)

Add you Tags

Product 5/20

Return to the Product List

Details

Download

Features:

* High resolution 16MP mini webcam usb with IMX298 Sensor

* Super high resolution 4656* 3496 resolution

* UVC camera free driver, Plug and Play

* Standard with 3m cable (1m/2m/5m... cable optional)

* With CS 2.8-12mm lens (Many other CS lens optional)

* Support different operating systems, compatible with different software

Specifications:

Model	ELP-USB16MP01-SFV (2.8-12)
Optional Models	ELP-USB16MP01-SFV (5-50) ELP-USB16MP01-MFV (2.8-12) ELP-USB16MP01-MFV (5-50)
Sensor	IMX298
Sensor Size	1/2.8inch
Pixel Size	1.12um
Image Area	6.4mm x 5.3mm
Max. Resolution	4656(H) X 3496(V) 16 Megapixel
Compression Format	MJPEG / YUY2 (YUYV)
Resolution & Frame Rate	4656 x 3496 MJPEG@10fps YUY2@1fps 4208 x 3120MJPEG@10fps YUY2@1fps 4160 x 3120 MJPEG@10fps YUY2@1fps 4000 x 3000MJPEG@10fps YUY2@1fps 3840 x 2160 MJPEG@10fps YUY2@1fps 3264 x 2448MJPEG@10fps YUY2@1fps 2592 x 1944 MJPEG@10fps YUY2@1fps 2320 x 1744MJPEG@30fps YUY2@1fps 2048 x 1536 MJPEG@30fps YUY2@1fps 1920 x 1080MJPEG@30fps YUY2@5fps 1600 x 1200 MJPEG@30fps YUY2@5fps 1280 x 960MJPEG@30fps YUY2@10fps 1280 x 720 MJPEG@30fps YUY2@10fps 1024 x 768MJPEG@30fps YUY2@10fps 800 x 600 MJPEG@30fps YUY2@15fps 640 x 480MJPEG@30fps YUY2@30fps
Min Illumination	0.5 Lux
Shutter Type	Electronic Rolling Shutter / Frame Exposure
Connecting Port Type	USB2.0 High Speed
Free Drive Protocol	USB Video Class (UVC)
AEC	Support
AWB	Support
AGC	Support
Adjustable Parameters	Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White Balance, Backlight Contrast, Exposure
Lens Parameter	CS 2.8-12mm lens (CS 4mm, 6mm, 8mm, 5-50mm, 6-60mm... optional)
Power Supply	USB BUS POWER 4P-2.0mm Socket
Operating Voltage	DC5V
Working Current	180mA~240mA
Working Temperature	-10~70℃
Storage Temperature	-20~85℃
Weight	0.37kg/pcs
Cable	Standard 3m / Optional 1m,2m,5m...
Operating System Request	WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc. Linux with UVC (above Linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC
